IPC-PANEL-U _RIVIDATA

Key Features：
● 12.1” IP66 front-protected panel with capacitive or resistive touch.
● Intel® ultra-low voltage Core™ processors for power-efficient computing.
● Triple LAN including Intel® Gigabit controllers.
● Fanless sealed design for silent and durable operation.
● Wide temperature range and DC power input flexibility.
● Expandable storage and connectivity for versatile deployment.

More About This Product：

Category	Specification
Display	12.1" 4:3 screen, resolution 1024×768
Touch	Flat panel, 10-point capacitive (default), 5-wire resistive optional
Protection	Front panel IP66 (sealed with adhesive process)
Brightness	250 nits (default), 350/500/600 nits optional
Temperature Range	Default -20°C to 70°C, optional -30°C to 70/80°C
CPU	Intel® Core™ i7/i5/i3/Pentium®/Celeron® ultra-low voltage, low-power processors
Memory	1 × SO-DIMM DDR4 2666/2933/3200MHz, up to 32GB
Graphics	HDMI external display, Intel® HD Graphics, supports extended screen, synchronous/asynchronous touch
Networking	3 × Gigabit LAN: Intel® i219LM, i210AT, Realtek 8111H onboard socket, supports Wake-on-LAN and PXE boot
Storage	1 × M.2 2280 SATA/NVMe SSD, optional 1 × 2.5" HDD/SSDe
USB	4 × USB 3.0 (expandable with more USB 2.0)
COM	2 × COM, RS232/422/485 selectable via BIOS, expandable
Audio	Realtek ALC897 codec, Line-out, Mic-in, external 4Ω 3W / 8Ω 2W speaker supported
Indicators	Front panel LED: red (standby), blue (on)
Cooling	Fanless, sealed touch panel PC design
Operating Systems	Windows 7/10/11, Linux
Cooling	Fanless sealed chassis, optional external temperature-controlled fan
Power Input	DC 9–36V lockable, DC jack or 2-pin 5.08mm terminal
Watchdog	1–255 sec system reset
Mounting	Horizontal or vertical (multi-slot versions)
Environmental	Operating: -20°C to 60°C, Humidity: 0–95%, Vibration: SSD 5Grms, Shock: SSD 50G
Certifications	CE/FCC

IPC-PANEL-U

Stability. Reliability. Intelligence.

Engineering for Touch Environments. Trusted in Factories, Railways, Data Centres.
